SPECIFICATIONS

Application: Charger Controller,Solar System Controller,Voltage Controller,Solar Working Station,Lighting Controller

Battery type: Lead-acid/Lithium/LiFePO4 Battery

Brand Name: byx

Certificate: CE RoHS ISO9001

Charge mode: MPPT Automatic Max Power Tracking

Color: White

Function: Solar System Controller

MPPT efficiency: 99.9%

Max PV Power: 3200W

Max PV Voltage: 150V

Model Number: dm-2

OEM & ODM: Acceptble

Place of Origin: Guangdong, China

Product name: MPPT Solar Controller

Protection: Short Circuit Overload Overvolt Overtemp

Type: MPPT

USB output: 2 Ports

Item NO	DM130	DM140	DM160
Rated charging current Rated	30A	40A	60A
Rated discharge current	10A
USB output current	5V3A MAX	//
PV Maximum open circuit voltage	80V	100V	150V
PV Maximum input power	400W/12V 800W/24V	5500W/12 1100W/24V	400W/12V 1600W/24V 3200W/48V
MPPT tracking efficiency	≧99%
Conversion efficiency	≧98%
System voltage	12V24V auto adapt	12V24V auto adapt	12V24V 48V auto adapt
N.W.	800g	1300g	1400g
Size(mm)	195x132x63mm	217x148x65mm	232x163x75mm
