2025 Bigger Size 14 Inch Aluminum case Home Automation Smart Security in Wall Control Panel Pc
2025 Bigger Size 14 Inch Aluminum case Home Automation Smart Security in Wall Control Panel Pc
✅ Made In USA
✅ Quick Delivery
✅ Cruelty Free
BUNDLE & SAVE
Couldn't load pickup availability
-
Ordered
- - -
Order Ready
- - -
Delivered
2025 Bigger Size 14 Inch Aluminum case Home Automation Smart Security in Wall Control Panel Pc
SPECIFICATIONS
Brand Name: NONE
CPU: RK3568 Quad-core Cortex-A55 up to 2.0GHz
Dimension: 336.7*215.6*11.5mm
Interface: RJ45 ,RS485 ,DC , Type c
Material: Aluminum
Network: wifi ,Bule-tooth, Ethernet
Origin: Mainland China
Product Type: Smart Gateway
System: Android 11/Linux Debian 11 os option
Touch panel: 10 points capactive touch panel, IPS
brand name: Portworld
camera: No Camera
display type: IPS
feature: wifi
operation system: android 11 os/Linux debian
place of origin: Guangdong, China
private mold: Yes
resolution: 1920*1080
screen: ≥5.0"
screen resolution: 1920x1080
size: 14''
storage: 2gb+16gb/4gb+32gb
Email: 1813402553@qq.com
whatsapps: + 8617608479274
I'll reply you as soon as I get your message. Have a nice day!
Bigger Size 14 Inch Aluminum case Home Automation Smart Security in Wall Control Panel Pc
Features:
1.14" landscape display embedded in wall mount tablet
2. Suitable for 86 wall BOX, EU ,US gang Wall box
3. RK3568 Quad-core Cortex-A55 up to 2.0GHz
4. Android 11/Linux Debian 11 os option
5. POE function,Support Ethernet/WiFi/BT
6. Standard with Black Color , support customization
7. DC port competiable with 12V & 24V
8. Support Wake-up on Touch function
More OEM/ODM requirements is accepted!!
Specification sheet :
System | Dimension | 336.7*215.6*11.5mm | |
CPU | RK3568 Quad-core Cortex-A55 up to 2.0GHz | ||
System | Android 11/Linux Debian 11 os option | ||
RAM | 2G(4G Option) | ||
Rom | 32G | ||
Display | Display size | 14inch | |
Resolution | 1920*1080 | ||
Touch Panel | 5 points capactive touch panel, IPS | ||
Brightness | 300nit | ||
Network | WIFI | 802.11b/g/n ( 5G wifi option) | |
Bluetooth | BT 5.2 | ||
Ethernet | 10M/100M | ||
I/O ports | RJ45 | Ethernet interface input (RJ-45 cable support POE function) | |
USB Type C | Type C USB | ||
RS485 | RS485 A,B (RS232 Option) | ||
Set | Built- in | ||
Restart | Built- in | ||
Power suply | DC 12V /24V input | ||
Material | Metal case + Glass touch panel | Metal case + Glass touch panel | |
Features | Microphone | 2* Mic Built- in | |
Speaker | 1W*2pcs | ||
Media plays | Video | MOV 1080P / AVI / WMV / RM / RMVB / 3GP / MKV / MP4 / ASF/ VOB | |
Audio | MP3 / WMA / WAV / AAC / FLAC / OGG | ||
Entertainment | Video / Movie / Music / FM online | ||
Others | Camera | No | |
Battery | NO | ||
Color | Black (Silver /gold option) | ||
Mount | wall mounted / in wall & embedded | ||
Power consumption | 2x10W MAX | ||
Working temperature | .-5°~70° | ||
Language | Support multi-languages | ||
Warranty | 12 months | ||
About Sunworld /Portworld
Founded since 2008 a leading R&D manufacturer of tablets. Most of the products are proudly by our designed and engineered to the finest specifications. Sunworld products are comprised of high-quality aluminum, ABS and polycarbonate to provide a perfect solution for the customer.
With over 20 years of experience in the POE Tablet/Digital Signage/AIO Digital Signage/smart Home/Intelligent Retail industry, we recognized a growing need for quality-made electric products. We leverage our extensive industry knowledge and our ability to quickly custom design cases cover & mainboard to help customer to make reliable solutions.
Sunworld has high-level R & D team composed of Hardware/Software engineers, with a high level of industry-recognized R & D capabilities, a deep understanding of the project as well as the definition, development, production and service experience products, while also with high-end technology, manufacturing processes and manufacturing capabilities. We help customer make a reputation of delivering innovative solutions for any application or industry, such as the Hotel, Hospital, Supermarket, Smart home.
OEM & ODM service are highly support , or pls visit our factory for knowing further information.
1.Can you accept sample order?
A:Yes.
2.How long does it take to deliver the sample?
A:It depends on different products,it usually takes 10-15 days.
3.What's your Mini Order Quantity(MOQ)?
A:It depends on different products,for tablet pc 1000-2000 pieces,
4.What payment term you can accept?
A:For sample, T/T or West Union is available,for big order by T/T,West Union or L/C.
5.How to ship the goods to us?
A:For sample or small quantity,by DHL For big order,normally by sea shipment orby air shipment.
6.Can we have our own logo printed on the product or package?
A:For sample,it usually be neutral.For big order,it support customized logo.
7.How much will the customized logo cost?
A:For big order, if your quantity up to our MOQ, it usually be free.
